Product Type:CompactLogix Controller Module

Module Type:Processor Module

Wire Type:Copper

Communication Ports:1 Ethernet I/P; 1 RS232

Mounting:DIN Rail; Panel

Dimensions:118 x 70 x 87 mm (4.65 x 2.76 x 3.43 in.)

Weight:630 g (1.39 lb)

Nominal Input Voltage:24VDC

Input Voltage Range:19.2-31.2VDC

Power Consumption:100 VA @ 24V DC

Fuse Type:Wickmann 19193-6.3A Littelfuse 021706.3MXP

Backplane Compatibility:Single Slot - 1769 backplane compatible

    Engineered for efficiency and reliability, the Allen-Bradley AB 1769-L23E-QB1B is designed to meet the demands of modern industrial environments.

    This compact yet powerful controller is compatible with all CompactLogix and MicroLogix 1500 LRP Controllers, except for specific models like 1769-QBFC1B, 1769-L16x, and 1769-L18x, ensuring broad compatibility.

    Featuring an intuitive interface and robust connectivity options, it facilitates seamless integration with existing systems and supports advanced communication protocols, enhancing operational efficiency.

    With support for up to three (3) 1769 I/O modules, this controller provides ample flexibility for managing complex automation tasks in various applications.

    Built for durability and ease of use, the Allen-Bradley AB 1769-L23E-QB1B ensures long-lasting performance, backed by Allen-Bradley's commitment to quality and support.
