ALSTOM E32OUT series N895609510K, N895609010R, N895609100P Eurocard high-density digital output board, spare hardware for legacy steam turbine governing racks with TRENO bus architecture.

Product Overview

• Part No: N895609510K, N895609010R, E32OUT, N895609100P
• Brand: ALSTOM

• Category: E32OUT 32-Channel Digital Output ModuleN895609510K, N895609010R and N895609100P belong to ALSTOM E32OUT high-density digital output module family for turbine control systems. Different suffix letters represent successive hardware revisions, functionally interchangeable within matched TRENO bus control racks.This Eurocard plug-in module provides 32-channel digital logic outputs. It receives command data from ECPU main processor via backplane TRENO bus, converts internal logic signals into field drive signals to control relays, solenoid valves, trip circuits, auxiliary actuators and alarm indicators. Built-in opto-isolation, overcurrent protection and EMI filtering prevent external circuit interference and backfeed damage. It is a discontinued critical maintenance spare widely applied for overhaul of thermal power and combined-cycle power plant steam turbine governing & protection systems.

•


Core Features

• High density 32-channel digital output for turbine interlock, trip and auxiliary equipment control
• Optoelectronic galvanic isolation between field channels and internal rack circuit
• Short-circuit and overcurrent protection for each output channel
• Front panel LED status indicators for channel diagnostics and module fault alarm
• Standard Eurocard draw-out design supporting fast on-site replacement
• Reinforced multilayer PCB with gold-plated edge connectors for anti-vibration performance
• ESD & transient surge protection adapting severe power station electromagnetic environments

• Verified compliance with EMC, vibration and wide-range thermal cycling reliability tests

•


Technical Specifications

• Operating Supply: 24 VDC
• Form Factor: Standard Eurocard rack plug-in printed circuit board
• Operating Temperature: -10°C ~ +60°C
• Storage Temperature: -40°C ~ +85°C

• Protection Class: IP20 when installed inside control cabinet

•


Compatibility & Application

• Compatible with ALSTOM legacy turbine governing racks equipped with TRENO internal bus
• Widely deployed in thermal power plants, combined-cycle power stations and captive power facilities
• Used for turbine protection trip logic, valve interlock control, auxiliary system start/stop command output and fault alarm driving
