Power Rating (kW):0.4

Voltage:200 VAC

Servomotor Type:Flat; Pancake

Rated Speed (RPM):3,000

Max Speed (RPM):5,000

Mounting Type:Flange Mount

Encoder Type:Incremental Encoder

Bit Resolution:13 BIT

Constant Torque (Nm):1.27

Peak Torque (Nm):3.82

Peak Torque (in-oz):542

Constant Torque (in-oz):180

Constant Torque (in-lb):11.24

Peak Torque (in-lb):33.8

Brake:Yes

IP Rating:IP67

Approvals:UL; CE; cUL Recognized

    The Yaskawa UTSAE-B17CLE, SGMRS-06A2B-YR21 is a high-performance robotic servo encoder and motor, designed to deliver unparalleled precision and reliability in demanding industrial environments.

    Featuring a compact design and robust construction, this product ensures efficient operation and long service life, even under extreme conditions.

    With its high-resolution encoder and powerful motor, the Yaskawa UTSAE-B17CLE, SGMRS-06A2B-YR21 enables precise control and accurate positioning, making it ideal for applications requiring high accuracy and repeatability.

    This motor and encoder combination is engineered with advanced materials and technologies, ensuring durability and minimal maintenance requirements.

    The unit is equipped with the latest safety and diagnostic features, including IP67 protection against dust and water ingress, ensuring reliable operation in harsh environments.

    Backed by Yaskawa's commitment to quality and customer support, the UTSAE-B17CLE, SGMRS-06A2B-YR21 offers a comprehensive solution for automating complex robotic processes, enhancing productivity and efficiency.
