Number of Selectable Inputs:8

Number of Selectable Outputs:4

Relay Output:Available

Serial Communication Ports:1 supporting RS232 and RS485

Encoder Support:Embedded for multi-turn absolute encoders

External Logic Power:Option for maintaining actuator position during power loss

Compliance Status:Not compliant with EU RoHS directive

Drive Size:(198.12 x 144.27 x 72.64 mm)

Input Voltage Range:100-240VAC rms, 1-Phase

Frequency Range:47-63 Hz

Output Voltage Range:100-240VAC

Continuous Output Power:1kW

Continuous Output Current:5A

Intermittent Output Current:15A

Operating Temperature:-10°C to +50°C

Storage Temperature:-20°C to +60°C

    Engineered for high-performance and reliability, the Allen-Bradley 2098-DSD-010X Digital Servo Drive is a cornerstone in industrial automation. This drive boasts a compact yet robust design, optimized for seamless integration into complex machinery systems.

    Featuring eight selectable general purpose inputs, it allows for versatile connection options to monitor and control various aspects of the automation process. The four selectable general purpose outputs offer flexibility for initiating actions or controlling devices directly.

    With one serial communication port supporting both RS232 and RS485 standards, the 2098-DSD-010X ensures compatibility with a wide range of control systems and facilitates efficient data exchange. Its embedded support for multi-turn absolute encoders ensures precise position tracking, even under power loss conditions.

    The option to supply external logic power further enhances the drive's adaptability, enabling maintenance of actuator positions during power interruptions. This feature is crucial for maintaining system integrity and operational efficiency in demanding environments.

    Compact in size yet powerful in performance, the Allen-Bradley 2098-DSD-010X Digital Servo Drive is meticulously designed to deliver unparalleled precision and reliability. Whether in packaging lines, robotics, or any industry requiring meticulous control over mechanical movements, this drive is the trusted choice for achieving superior automation results.
