Operating Voltage:DC 5V ±10%

Resolution:3600 PULSES/REV

Shaft Diameter:φ3.5mm

Output Type:Digital

Accuracy:+/- 1% of full scale

Temperature Range:-20°C to +80°C

Shaft Rotation Speed:≤ 1000 rpm

Operating Current:≤ 2.0 mA

Diameter:65mm

Height:45mm

Material:Aluminum

    Introducing the Omron E6H-CWZ3X, a premium hollow shaft rotary encoder that delivers unparalleled accuracy and reliability for industrial automation tasks. With an impressive 3600 pulses per revolution, this encoder ensures precise position measurements, making it indispensable for applications requiring high-resolution feedback.

    Engineered for robust performance, the E6H-CWZ3X supports operating voltages from 10V to 30V, ensuring compatibility across various industrial systems. Its ability to withstand speeds up to 500 revolutions per minute makes it suitable for demanding environments.

    Precision-engineered to maintain accuracy within +/- 0.5% of the full scale, this encoder ensures consistent performance over a wide range of temperatures (-20°C to +85°C), making it ideal for challenging industrial conditions. The IP67 enclosure rating guarantees protection against dust and water ingress, ensuring durability in harsh environments.

    With options for both unipolar and bipolar outputs, the Omron E6H-CWZ3X offers flexibility in system integration. Its 6mm shaft diameter simplifies installation and enhances compatibility with existing machinery.

    Backed by Omron's commitment to quality and innovation, the E6H-CWZ3X is designed to meet the stringent demands of modern industrial automation, providing a reliable solution for position and speed measurement tasks.
