Board Size:3U

Connector Count:15

Power Supply Compatibility:Wide voltage range

Operating Temperature Range:-40°C to +70°C

Material:Aluminum

Environmental Certification:UL, CE, EN50155

Load Capacity:Up to 20A per channel

Data Transmission Speed:RS-232/422/485

    Engineered for demanding industrial environments, the SCHROFF 23000-015 Backplane Board is a cornerstone component in modern automation systems, boasting robust construction and superior reliability.

    Featuring an innovative aluminum alloy design, it optimizes heat dissipation, ensuring consistent performance even under extreme conditions.

    With its wide operating voltage range from 12VDC to 36VDC, this backplane board is compatible with a broad spectrum of power sources, enhancing its versatility across different industrial applications.

    Equipped with a data transfer rate of 100Mbps, it ensures fast and reliable communication between modules, critical for efficient operation in complex automation setups.

    The backplane supports up to 48 slots, allowing for scalable and flexible configuration tailored to specific industrial requirements. This modular design enables easy expansion and customization without compromising on performance or stability.
