Model Number:1756-OF4

Module Type:Analog Output

Connector Type:DIN Rail Mount

Signal Type:4-20 mA, 0-10 VDC

Supply Voltage Range:12-48 VDC

Operating Temperature:-10°C to +60°C

Communication Interface:RS-485

Dimensions (WxHxD):125mm x 95mm x 75mm

Weight:0.5kg

    The AB 1756-OF4 Analog Output Module is engineered for precision and reliability in industrial automation environments. Its compact design ensures efficient use of space on control panels, while its high-precision signal output guarantees accurate control signals for a wide range of industrial applications.

    Featuring a robust power supply compatible with DC 24V systems, this module is designed to withstand the harsh conditions typical of industrial settings. It offers a current rating of up to 10mA, providing flexibility for various load requirements.

    With the ability to generate analog signals in either 0-10V or 4-20mA formats, the AB 1756-OF4 module is versatile enough to meet the needs of diverse industrial processes. Its accuracy of +/- 1% of full scale ensures minimal error margins, critical for maintaining high operational efficiency.

    Operated within a temperature range of -20°C to +60°C and a humidity level of 5% to 95% non-condensing, the module is designed for long-term reliability in varying environmental conditions. This makes it suitable for use in industries where environmental extremes are common.

    For ease of installation and maintenance, the AB 1756-OF4 Analog Output Module comes with panel mounting capabilities, simplifying integration into existing control systems. Its straightforward configuration and compatibility with Allen-Bradley PLCs make it an ideal choice for seamless automation solutions.
