Touch Screen Type:Resistive

Display Size:5.7"

Resolution:QVGA, 320 x 240 pixels

Nominal Voltage:18 to 30 VDC

Nominal Current:0.5 A

Power Consumption:Typically 12 W

Weight:1.76 kg

Protection Rating:IP65 (front side)

Slots:1 aPCI slot

Memory:128 MB SDRAM, 512 KB SRAM

Network Interface:ETH 10/100, RS232, 2x USB

Operating Temperature:-10°C to +55°C

    Crafted with precision and reliability, the B&R 4PP220.0571-65 Touch Screen Display is designed to meet the demands of harsh industrial environments. Its resistive touch technology ensures durability and responsiveness, even under extreme conditions.

    Featuring a 5.7-inch QVGA monochrome LCD display with touch functionality, this device offers clear visibility and intuitive user interaction, making it ideal for operators requiring quick access to critical information.

    Equipped with an aPCI slot, the B&R 4PP220.0571-65 supports additional expansion, allowing for flexible customization according to specific application requirements. Its onboard memory ensures sufficient space for storing data and software.

    With its compact size and lightweight design, the B&R 4PP220.0571-65 Touch Screen Display can be easily integrated into any control panel without compromising on functionality or aesthetics.

    Designed to withstand the rigors of industrial use, this touch screen display comes with an IP65 front-side protection rating, safeguarding against dust and water ingress. It operates efficiently within a wide temperature range, ensuring reliable performance throughout the year.
