Number of Channels:8

Signal Range:-10V to +10V or 0V to 10V

Sampling Rate:100Hz per channel

Power Supply:DC 24V

Communication Interface:Modbus RTU

Operating Temperature:-20°C to +70°C

Humidity:5% to 95% non-condensing

Dimensions:161mm x 114mm x 93mm

Material:Aluminum enclosure with IP65 rating

    The AB 1797-IE8NF External Analog Input Module is engineered for durability and reliability, making it ideal for demanding industrial environments. Its robust IP67 enclosure ensures protection against dust and water ingress, enabling its use in harsh conditions without compromise.

    Featuring eight independent channels, this module allows for the simultaneous monitoring and processing of multiple signals, significantly enhancing operational efficiency. Each channel supports a wide signal range from -10V to +10V DC, providing versatility in various industrial applications.

    With a supply voltage of 24V DC, the module is compatible with a wide range of power sources commonly found in industrial settings, ensuring seamless integration and operation. The module's temperature range of -40°C to +85°C guarantees reliable performance across extreme climates, from cold storage facilities to hot industrial plants.

    Designed for modular DIN rail installation, the AB 1797-IE8NF is easy to install and can be conveniently integrated into existing control systems. Its RS-485 communication interface facilitates efficient data exchange with other system components, enabling advanced automation and control strategies.

    This module's compact size and lightweight design (0.7kg) make it suitable for space-constrained applications without sacrificing functionality. Its compatibility with standard industrial protocols and its rugged construction ensure longevity and cost-effectiveness in long-term industrial setups.
