Model Type:SLC500

Model Number:1746-NI16I

Manufacturer:Allen Bradley

Channels:16

Input Type:Common Mode Voltage Range: Plus/Minus 10.25 V Relative To Analog Common Terminal

Input Formats:Plus/Minus 20 MA, 4 – 20 MA, 0 – 1 MA, 0 – 20 MA

Max Voltage Input:Plus/Minus 8 V Between Any Two Signal Terminals

Current Rating:Backplane: 125 MA At 5 VDC, 75 MA At 24 VDC

Isolation:500 VAC Isolation For 1 SEC

Power Rating:Backplane: 2.425 W, Enclosure: Open Type

    This Allen Bradley 1746-NI16I module is a robust solution for high-precision analog signal processing, essential for maintaining optimal performance in industrial automation environments.

    With its advanced technology, this module ensures accurate measurement and conversion of physical quantities such as temperature, pressure, and flow into digital signals, facilitating seamless integration with control systems.

    Featuring a wide common mode voltage range and a comprehensive set of input types, the 1746-NI16I is compatible with diverse sensor outputs, making it suitable for a broad spectrum of industrial applications.

    The module's isolation feature provides protection against electrical interference, ensuring reliable operation even in harsh environments. Its efficient power management system optimizes energy consumption without compromising performance.

    Designed for ease of integration, the Allen Bradley 1746-NI16I is compatible with Allen Bradley's extensive ecosystem of industrial automation components, enabling seamless setup and configuration for complex control systems.
