Extended Product Type:2-channel isolated barrier

Product ID:KCD2-SR-EX2

P+F Type Designation:Switch

Supply Voltage:24 V DC

Inputs:["Dry contact","NAMUR"]

Output Type:Relay contact

Line Fault Detection (LFD):Enabled

Housing Width:12.5 mm

Safety Compliance:Up to SIL 2 according to IEC 61508

Signal Type:Digital Input

Rated Voltage:19 … 30 V DC

Power Consumption:<= 600 mW

Connection:["Power Rail","Terminals"]

Mass:~100 g

Mounting:On 35 mm DIN mounting rail according to EN 60715:2001

    Unleash the power of precision control with the P+F KCD2-SR-EX2 Switch Amplifier, a cutting-edge solution engineered to meet the most stringent industrial demands.

    This amplifier is equipped with a dual-channel, isolated barrier design, ensuring high reliability and robust performance even under the harshest conditions.

    Featuring a 24 V DC supply, the KCD2-SR-EX2 delivers consistent and stable power to your systems, backed by its innovative Power Rail technology for efficient power management.

    Dry contact or NAMUR inputs provide versatile connectivity options, while the relay contact output ensures reliable signal transmission and response.

    Equipped with Line Fault Detection (LFD), the KCD2-SR-EX2 continuously monitors system integrity, safeguarding operations against unexpected disruptions.

    Designed for durability and safety, this amplifier meets up to SIL 2 standards as per IEC 61508, making it an ideal choice for applications requiring the highest levels of safety.
