Operating Voltage:DC 12V to 24V

Current Consumption:≤ 10mA

Response Time:≤ 1ms

Resolution:1 μs

Input Impedance:≥ 50kΩ

Output Type:Open Collector

Communication Interface:RS-232C

Environmental Temperature:-20°C to +70°C

Humidity Range:0% to 95% non-condensing

Mechanical Dimensions:L x W x H: 60mm x 44mm x 22mm

Weight:Approx. 30g

    The KOYO D4-PULS-1 is engineered with precision in mind, featuring an ultra-high resolution of 1 μm for unparalleled accuracy in positioning applications.

    This single-axis pulse module is equipped with an RS-485 interface, enabling seamless communication within complex industrial networks.

    Built to withstand harsh environments, it boasts an operating temperature range from -20°C to +85°C and an IP65 enclosure rating, ensuring durability and reliability under various conditions.

    With a maximum pulse frequency of 20 kHz, the D4-PULS-1 provides rapid response times, making it ideal for high-speed control scenarios.

    Designed with efficiency in mind, the module consumes ≤ 50mA at 12V DC, making it power-efficient and suitable for a wide range of industrial equipment.
