Model Type:SLC500

Model Number:1746-OB16

Manufacturer:Allen Bradley

Digital DC Output Module:Yes

Number of Channels:16

Input Voltage:24 VDC

Output Voltage Range:10 – 50 VDC

On-State Voltage Drop:1.2 V

Off-State Output Leakage:1 MA

Load Capacity:1 MA

Current Rating:Backplane: 0.28 A, Continuous Current Per Output: 0.25 A at 60 °C, Continuous Current Per Module: 4 A at 60 °C

Isolation:Communication Circuits: 500 VDC, Backplane: 1500 VAC

Processor:SLC 500

Enclosure Type:Open Type

Mounting Method:Chassis

Temperature Rating:0 – 60 °C

Environmental Conditions:5 – 95%

    Engineered with precision and reliability, the Allen Bradley 1746-OB16 digital DC output module is a cornerstone for advanced industrial automation solutions. This robust module ensures consistent performance and efficient operation in a wide range of applications, from manufacturing lines to complex control systems.

    Featuring 16 channels capable of handling high and low currents, this module is designed to provide unparalleled flexibility and control. Its ability to operate within a broad voltage range of 10 to 50 VDC makes it suitable for diverse environments and processes.

    With an on-state voltage drop of just 1.2V and a leakage current of 1 MA, the Allen Bradley 1746-OB16 guarantees minimal power loss and optimal performance, even under demanding conditions. Its isolation capabilities protect against electrical disturbances, ensuring system integrity and safety.

    Built for durability and ease of integration, the open-type enclosure allows for straightforward installation and maintenance, while the chassis mounting option facilitates seamless setup in existing industrial control systems. The temperature rating of 0 to 60 DEG C ensures reliable operation in most industrial settings.

    Designed with user convenience in mind, the Allen Bradley 1746-OB16 includes all necessary specifications for streamlined integration into complex automation projects. Whether you're upgrading an existing system or starting fresh, this module offers a reliable foundation for your industrial automation needs.
